Strip Forming Machine


Strip Forming Machine

We are Manufacturer, Supplier, and Exporter of Rolling Shutter Strip Forming Machine. This machine has great strength and robust structure. We use latest technology and premium grade steel to make the Strip Forming Machine. Our Strip Forming Machine is easy to operate and highly safe.

Necessary Specification of machine is given below :
  • Fitted with number of rolls
  • Desired strip are formed in single pass
  • Best for making rolling shutters
  • Lubricant arrangements at gunmetal bearing
  • High machine speed

Salient Features :
  • Very low maintainace
  • Sturdy construction
  • Durable
  • Cost effective

Availability :
  • Various sizes
  • Customized designs


Chart

Chart

Technical Specification

Input coil width Standard 114.0 MM 121.0 MM 130.0MM
Input Maximum Thickness 1.20 MM (18 SWG) 1.20 MM (18 SWG) 1.20 MM (18 SWG)
Input Minimum Thickness 0.70 MM (22 SWG) 0.70 MM (22 SWG) 0.70 MM (22 SWG)
Output Length No limit No limit No limit
No. Of Rollers 6 Sets 6 Sets 8 Sets
Electric Motor (H.P.) 5 H.P 5 H.P 7.5 H.P
Output Width Round Type 76.0 MM 83.0 MM 90.0 MM
Output Width Flat Type 82.0 MM - -
Output Speed 28 to 30 Ft./Min 28 to 30 Ft./Min 28 to 30 Ft./Min
Machine Weight 950.0 Kg. (Approx) 1100.0 Kg. (Approx) 1200.0 Kg. (Approx)
